D3646-S

Industrie-Mainboard ATX-Formfaktor

• 8th Generation Intel® Coreâ„¢ i7/i5/i3
• Socket LGA1151 – up to 95W TDP
• Chipsatz: Intel® C246 Express Chipset
• Integrated Intel HD Graphics
• DDR4-2666, Dual Channel, ECC support
• 4 DIMM sockets, up to 64GB memory
• PCI Express x16 (Gen.3) & 2 x PCI (32Bit/33MHz Rev. 2.3)
• Intel® UHD Graphics (DX12)
• 1x DVI-D, 2x DP V1.2
• Intel® High Definition 5.1 Audio; Infineon TPM V2.0
• 6x USB 2.0, 4x USB 3.1 Gen1, 2x USB 3.1 Gen2, 1 x USB 3.1 Gen2 stick socket
• BIOS-POST/-Boot & OS – HW Watchdog onboard

Technische Daten

D3641-S

Industrie-Mainboard microATX-Formfaktor

• 8th Generation Intel® Coreâ„¢ i7/i5/i3
• Socket LGA1151 – up to 95W TDP
• Chipsatz: Intel® C246 Express Chipset
• Intel® UHD Graphics (DX12)
• DDR4-2666, Dual Channel, ECC support
• 4 DIMM sockets, up to 64GB memory
• PCI Express x16 (Gen.3) & 2 x PCI (32Bit/33MHz Rev. 2.3)
• Intel® UHD Graphics (DX12)
• 1x DVI-D, 2x DP V1.2
• Intel® High Definition 5.1 Audio; Infineon TPM V2.0
• 6x USB 2.0, 4x USB 3.1 Gen1, 2x USB 3.1 Gen2, 1 x USB 3.1 Gen2 stick socket
• 6x SATA 6G/s incl. RAID support, parallel port (internal pin header)
• BIOS-POST/-Boot & OS – HW Watchdog onboard

Technische Daten

D3446-S

Industrie-Mainboard ATX-Formfaktor

• 6th Generation Intel® Coreâ„¢ i7/i5/i3
• Socket LGA1151 – up to 80W TDP
• Chipsatz: Intel® C236 Express Chipset
• Integrated Intel HD Graphics
• DDR4 2133 SDRAM (UDIMM)
• DDR4 2400 SDRAM (UDIMM) ECC / Non-ECC
• Intel® HD Graphics; PCI Express Gen3
• Multichannel Audio & Dual Intel GbE LAN onboard
• USB 2.0/3.0 and USB 2.0 socket (stick) onboard
• Trusted Platform Module V2.0 (Intel) onboard
• BIOS-POST/-Boot & OS – HW Watchdog onboard

Technische Daten

D3441-S

Industrie-Mainboard microATX-Formfaktor

• 6th Generation Intel® Coreâ„¢ i7/i5/i3
• Socket LGA1151 – up to 80W TDP
• Chipsatz: Intel® Q170 Express Chipset
• Integrated Intel HD Graphics
• DDR4 2133 SDRAM (UDIMM)
• DDR4 2400 SDRAM (UDIMM)
• Intel® HD Graphics; PCI Express Gen3
• Multichannel Audio & Dual Intel GbE LAN onboard
• USB 2.0/3.0 and USB 2.0 socket (stick) onboard
• Trusted Platform Module V2.0 (Intel) onboard
• HW Watchdog onboard

Technische Daten

D3402-B

Industrie-Mainboard microATX-Formfaktor

• 6th Generation Intel® Coreâ„¢ i7/i5/i3
• Socket LGA1151 – up to 65W TDP
• Chipsatz: Intel® Q170 Express Chipset
• Integrated Intel HD Graphics
• DDR4 2133 SDRAM (UDIMM)
• DDR4 2400 SDRAM (UDIMM)
• Intel® iAMT 11.0 / vPro 2015
• Onboard Support for M.2 SSD (PCIe or SATA)
• Intel® HD Graphics
• Multichannel Audio & Intel GbE LAN onboard
• USB 2.0/3.0 and USB 3.0 Socket (Stick) onboard
• Trusted Platform Module V2.0 (Infineon) onboard
• HW Watchdog onboard

Technische Daten

D3445-S

Industrie-Mainboard ATX-Formfaktor

• 6th Generation Intel® Coreâ„¢ i7/i5/i3
• Socket LGA1151 – up to 65W TDP
• Chipsatz: Intel® H110 Express Chipset
• Integrated Intel HD Graphics
• DDR4 2133 SDRAM (UDIMM)
• Intel® HD Graphics; PCI Express Gen3
• Multichannel Audio & Dual Intel GbE LAN onboard
• USB 2.0/3.0 onboard
• Trusted Platform Module V2.0 (Intel) onboard
• BIOS-POST/-Boot & OS – HW Watchdog onboard

Technische Daten

D3236-S

Industrie-Mainboard ATX-Formfaktor

• 4th Generation Intel® Coreâ„¢ i7/i5/i3 (Haswell)
• Socket LGA1150
• Chipsatz: Intel Q87 Express
• Integrated Intel HD Graphics
• 4x DDR3 1333/1600MHz DIMM up to 32GB
• 1x DVI-I, 2x DisplayPort V1.2
• 2x USB 3.0, 6x USB 2.0
• 2x GBit Intel i217LM / Intel i210AT Ethernet Controller
• Supports RAID 0/1/5/10
• 1x PCIe(x16) (Gen3)
  1x PCIe(x16) (4 Lanes, Gen2)
  1x PCIe(x8) (1 Lane, Gen2)
  4x PCI (32Bit, 33 MHz, Rev. 2.3)

Technische Daten

NEU

HD310-Q87

Industrie-Mainboard Micro ATX-Formfaktor

• 4th Generation Intel® Coreâ„¢ i7/i5/i3 (Haswell)
• Socket LGA1150
• Chipsatz: Intel Q87
• Integrated Intel HD Graphics
• 4x DDR3/DDR3L 1600MHz DIMM up to 32GB
• 1x HDMI, 1x DVI-I
• 4x USB 3.0, 8x USB 2.0
• 2 x GB LAN,
• 1 Parallel, 6x COM
• 6x SATA3 up to 6Gb/s
• Supports RAID 0/1/5/10
• 2x PCIe x16, 1 PCIe x4, 1 PCIe x1

Technische Daten

NEU

HD620-H81D 2x ISA

Industrie-Mainboard ATX-Formfaktor

• 4th Generation Intel® Coreâ„¢ i7/i5/i3 (Haswell)
• Socket LGA1150
• Chipsatz: Intel H81
• Integrated Intel HD Graphics
• 2x DDR3 1600MHz DIMM up to 16GB
• 1x VGA, 1x DVI-D
• 2x USB 3.0, 4x USB 2.0
• 2x GBit LAN
• 2x RS232/422/485
• 2x SATA3.0, 2x SATA2.0
• 1x PCIe(x16), 1x PCIe(x4), 4x PCI, 2x ISA

Technische Daten

NEU

IMB-Q870

Industrie-Mainboard Micro ATX-Formfaktor

• 4th Generation Intel® Coreâ„¢ i7/i5/i3 (Haswell)
• Socket LGA1150
• Chipsatz: Intel Q87
• Dual-channel DDR3 1600/1333MHz
• Intel PCIe GbE mit Intel AMT 9.0
• HDMI, iDP, DVI und VGA
• PCI-Express 3.0 bei 8GT/s I/O Bandbreite
• USB 3.0 und SATA 6Gb/s

Technische Daten

NEU

IMBA-Q870

Industrie-Mainboard ATX-Formfaktor

• 4th Generation Intel® Coreâ„¢ i7/i5/i3 (Haswell)
• Socket LGA1150
• Chipsatz: Intel Q87
• Dual-channel DDR3 1600/1333MHz
• Intel PCIe GbE mit Intel AMT 9.0
• HDMI, iDP, DVI und VGA
• PCI-Express 3.0 bei 8GT/s I/O Bandbreite
• USB 3.0 und SATA 6Gb/s

Technische Daten

IMB-770

Industrie-Mainboard ATX-Formfaktor

• Intel® Coreâ„¢ i7/i5/i3 (Ivy Bridge and Sandy Bridge)
• Socket LGA1155
• Chipsatz: Intel Q77
• Integrated Intel HD Graphics Built-in Visuals
• 4x DDR3 1600MHz DIMM up to 32GB
• 1 x D-Sub, 1 x HDMI, 1 x DisplayPort
• 4x USB 3.0 , 9x USB 2.0
• 2x SATA3, 2x SATA2
• 4x PCI, 1x mini-PCIe, 1x mSATA, 3x PCIE (x16/x4/x1)
• 1x CFast Card Socket
• Gigabit LAN : 1x Intel 82579LM, 1x Intel 82583V
• 1x TPM Header

Technische Daten

SB331-IPM

Industrie-Mainboard Micro ATX-Formfaktor

• 2nd and 3rd Generation Intel® Coreâ„¢ i7/i5/i3
• Socket LGA1155
• Chipsatz: Intel Q67
• Integrated Intel HD Graphics
• 2x DDR3 1600MHz DIMM up to 16GB
• 1x HDMI, 1x DVI-I
• 14 USB 2.0
• 2x SATA3, 4x SATA2
• 2x PCIE (x16), 2x PCIe (x1)
• 3x LAN, 2x COM

Technische Daten

MB-960 1 x ISA

Industrie-Mainboard ATX-Formfaktor

• Intel® Coreâ„¢ i7/i5/i3, Pentium
• Socket LGA1155
• Chipsatz: Intel® Q67 Express
• 4 x DDR3 1066/1333 MHz SDRAM up to 16GB
• 12x USB 2.0, 2x USB 3.0, 4x COM,
• 2 x Gigabit LAN
• 4 x PCI , 1x PCI-E(x16),1x PCI-E(x4)
• 1 x ISA
• 2x SATA 3.0 , 4x SATA 2.0
• Supports DVI-I, DVI-D, HDMI
• Watchdog timer, 4+4 Digital I/O

Technische Daten

CL630-CRM

Industrie-Mainboard ATX-Formfaktor

• 2nd and 3rd Generation Intel® Xeonâ„¢ und Coreâ„¢
• Socket LGA1155
• Chipsatz: Intel® C216
• 4x DDR3 DIMM up to 32GB
• 4 USB 3.0 , 8 USB 2.0 , 6 COM , 2x Gigabit LAN ports
• 2 PCIe x16 , 2 PCIe x4 , 1 Mini PCIe, 3 PCI
• 2x SATA 3.0 , 4x SATA 2.0 , 1 IDE

Technische Daten

SB630-CRM

Industrie-Mainboard ATX-Formfaktor

• 2nd and 3rd Generation Intel® Coreâ„¢ i7/i5/i3
• Socket LGA1155
• Chipsatz: Chipsatz: Intel® Q67
• 4x DDR3 DIMM up to 32GB
• 12 USB 2.0 , 6 COM , 2x Gigabit LAN ports
• 1 PCIe x16,1 PCIe x4, 1 PCIe x1 oder 1 Mini PCIe und 4 PCI
• 2x SATA 3.0 , 4x SATA 2.0 , 1x 1 IDE

Technische Daten

EOL = End of Life

IMBA-9454G 6 x PCI

Industrie-Mainboard ATX-Formfaktor

• Intel® Core 2 Duo / Pentium 4/ Pentium D/ Celeron D CPU´s
• Socket LGA 775
• FSB 533/800/1066
• Chipsatz: Intel® 815
• Dual Gigabit LAN , T-Base TX LAN
• 6 x PCI, 1 x PCIe(x16)
• RS-232, USB, LPT

Technische Daten

MB-i965Q 1 x ISA

• ATX-Motherboard

• Intel® Coreâ„¢ 2 Duo/Pentium® Celeron® D

• Max. 4GB DDR2 DIMM

• 10 x USB2.0

• 2 x COM Ports

• 5 x PCI Slots

• 1 x ISA Slot

• 1 x PCIex16


Technische Daten

P4LA 1 x ISA

Industrie Mainboard ATX-Formfaktor

• Prozessor: Intel® Celeron M / Pentium M Low Power CPU, Sockel 479
• Prozessor: Intel® Core2 Duo CPU
• Chipsatz: Intel® 945G Express
• 4 x PCI, 1 x ISA Slot

Technische Daten

P4BWA 2 x ISA

Industrie Mainboard ATX-Formfaktor

• Prozessor: Intel® Core2Duo & Quad, Pentium D
• Socket LGA 775
• FSB 533/800/1066 MHz
• Chipsatz: Intel® Q965 Express
• Dual Gigabit LAN
• onBoard SATA Raid
• PCI-Express X16 / X4 , 1 x Mini-PCI , 4 x PCI & 2 x ISA
• RS-232/422/484 , USB,IrDA, LPT

Technische Daten
